AUZEUNER RTL-SDR RTL2832U R828 (R820T2 Enhanced Version) 0.5PPM TCXO DAB - Software Defined Radio

This is a new generation software-defined radio receiver RTL-SDR with RTL2832 ADC chip, 0.5 PPM TCXO, SMA F connector, and aluminum housing with passive cooling.

With a bandwidth ranging from 25 MHz to 1700 MHz, it is perfect for use as a radio scanner with freely available computer-based software such as SDR, HDSDR, SDR-Radio, Linrad, GQRX, or SDR Tap on Android.

It operates on Windows, MacOS, Linux, Android, and even on computers with integrated Linux like Raspberry Pi.

It is great for applications such as general radio scanning, air traffic monitoring, public safety radio, ADS-B air radar, AIS ship radar, ACARS, walkie-talkies, P25/MotoTRBO digital voice, POCSAG, weather balloons, APRS, NOAA weather satellites APT, Meteor M2 satellites, radio astronomy, monitoring meteor scatter, DAB, or as a low-cost pan-adapter for traditional amateur radios.

This model adopts the new RTL ADC solution using an improved tuner, comes with a 0.5 PPM TCXO (no offset, and precise tuning with an initial temperature drift compensation at 1 PPM and 0.5 PPM), with enhanced component tolerances and SMA F connector.

It requires a USB 2.0 port and works on USB 3.0 ports (note that we cannot guarantee it works on all USB 3.0 ports; please ensure your PC has an integrated USB 2.0 port).

• Fully assembled and ready to use.
• Aluminum case.
• Compact dimensions.
• Operating frequency from 25 MHz to 1760 MHz.
• Copper VHF & UHF ranges from 25 MHz to 1700 MHz.
• Reception modes AM, NFM, FM, DSB, USB, LSB, and CW.
• Temperature compensated 0.5 PPM TCXO.
• Gold-plated SMA antenna connectors are more durable and have lower insertion losses.

Specifications:

• Model: AUZEUNER RTL-SDR-G1
• IC Interface: AUZEUNER RTL2832U
• Tuner IC: Rafael Micro R820T2
• Accuracy: 0.5PPM (maximum)
• Instantaneous bandwidth: 2.4MHz (nominal); 3.2MHz (maximum)
• Frequency range: 25MHz-1760MHz (nominal)
• Antenna input: female SMA
• Dimensions (SDR only): 6.7cm*2.5cm*0.9cm

Package contents:

1x SDR receiver

1x FM antenna
