BMS module HXYP-SH-10S 10-cell 42V 14A

BMS module HXYP-SH-10S 10-cell 42V 14A

Battery Protection and Charging Module (BMS) for 10 Li-ion cells with individual cell monitoring. Suitable for nominal voltages of lithium batteries of 3.6V, 3.7V (including 18650, 26650).


Technical Parameters:

• Model: HXYP-6S-MT10S-SH10
• Charging Voltage: 42V
• Continuous Discharge Current: 14A
• Maximum Discharge Current: 20A
• Overcharging Voltage (per cell): 4.25V±0.05V
• Under-voltage (per cell): 2.5±0.05V
• Balancing Current: 56mA
• Static Current: 30uA
• Over-temperature Protection: -10℃~+70℃
• Weight: 10 g
• Dimensions: 66x40x9 mm

Note:

Upper limit current calculation: Battery 1C, capacity 2000 equals:
2Ah*1=2A upper limit operating current.
3C battery, capacity 2000 equals
2Ah*3=6A upper limit operating current.
For products with currents higher than 3A, the battery discharge rate must be higher than 3C.
If the battery heats up during use, it means that the battery discharge rate is not suitable for use. In this case,
it should not be used for extended periods, otherwise the battery will be damaged quickly.

This lithium battery protection board should not be used for LiFePO4 batteries, LED lights, cordless drill batteries, e-bike batteries, toy cars, etc.
