DA-100 Single-Phase LED Ammeter DIN with Display
DA-100 Single-Phase LED Ammeter DIN with Display
The DA-100 is a single-phase digital ammeter designed for DIN rail mounting, equipped with an LED display that measures current in the range of 0-200A. More
16,20 EUR
incl. VAT
The DA-100 is a single-phase digital ammeter designed for DIN rail mounting, equipped with an LED display that measures current in the range of 0-200A. More
DA-100 Single-Phase LED Ammeter DIN
The DA-100 is a single-phase digital ammeter designed for mounting on a DIN rail. It features an LED display and measures current in the range of 0-200A.
Specifications:
- Model: DA-100
- Power Supply: 150-250V AC
- Operating Frequency: 50/60Hz
- Phase: Single-phase Meter
- Current Measurement Range: 0.2-200A
- Protection Class: IP44
- Display: 3-digit 8mm display
- Connection Type: Direct connection
- Current Transformer: AT100
- Display Color: Red
- Connection Type: Terminal connection
- Operating Temperature: -5°C to 55°C
- Dimensions: 35.4x95x60mm (1.39x3.74x2.36 inches)
- Weight: 169g (0.37 lbs)
Package Contents:
- 1x DA-100 LED ammeter
- 1x Current transformer AT100
Model Selection:
| Model | Phase | Display | Type | Measurement | RS-485 |
| DIN-U | 1 | LED | 35mm DIN rail | Voltage (V) | No |
| DIN-F | 1 | LED | 35mm DIN rail | Frequency (Hz) | No |
| DVF | 1 | LED | 35mm DIN rail | Voltage and Frequency (V/Hz) | No |
| DA-100 | 1 | LED | 35mm DIN rail | Current (A) | No |
| DAV-100 | 1 | LED | 35mm DIN rail | Current and Voltage (A/V) | No |
