Dimmer DC 12-24V, 8A module - quality brightness controller
The Pulse Width Modulation (PWM) controller is designed to control the brightness of lighting devices (LED strips, LED bars, conventional bulbs, halogen bulbs, etc.) powered by 12 to 24V.
The light intensity is adjusted by turning the potentiometer. (In the leftmost position of the potentiometer, the light is completely off; in the rightmost position, the brightness is at maximum).
- Power Supply: 12V-24V DC
- Maximum Power: 8A / 192W
- PCB Dimensions: 30mm x 40mm.
- Operating Temperature: -20 to 60 °C
- Weight: 25g
Warning! High-quality dimmer!
