IEXP-502 Industrial Fanless PC, Intel Core i3/i5/i7, Triple HDMI, 2.5G LAN

IEXP-502 Industrial Fanless PC, Intel Core i3/i5/i7, Triple HDMI, 2.5G LAN

The IEXP-502 is a high-performance industrial fanless PC designed for advanced industrial automation, logistics, medical systems, and edge computing applications.
Powered by 12th Gen Intel® Core™ processors (Core i3, i5, or i7), this rugged device supports triple display output via HDMI, high-speed DDR5 memory up to 32GB, and NVMe storage for maximum performance.

It features three Intel i226-V 2.5G LAN ports, making it ideal for networking and industrial IoT applications.
With wide temperature tolerance (-20°C to +50°C), TPM 2.0 security, and multiple mounting options (VESA, wall mount, DIN-rail), the IEXP-502 delivers reliable and flexible performance even in demanding environments.

The system supports M.2 expansion slots for WiFi, Bluetooth, 4G/5G modules, and external SIM cards, making it future-proof for connectivity needs.

Specifications:

• Model: IEXP-502

• Processor Options:

  • Intel® Core™ i3-1215U, 6 cores / 8 threads, Turbo up to 4.4 GHz

  • Intel® Core™ i5-1235U, 10 cores / 12 threads, Turbo up to 4.4 GHz

  • Intel® Core™ i7-1255U, 10 cores / 12 threads, Turbo up to 4.7 GHz

• Chipset: Alder Lake

• Memory: 1 × DDR5 4800MHz SODIMM, up to 32 GB

• Storage:

  • 1 × M.2 2280 M-key (NVMe only)

  • 1 × 2.5" SATA HDD/SSD

• Graphics: Intel® UHD Graphics

  • 3 × HDMI (4096 × 2160 @ 60Hz) – triple display, synchronous/asynchronous

• Networking: 3 × Intel i226-V 2.5G LAN

• Expansion Slots:

  • 1 × M.2 2230 E-key (WiFi, Bluetooth)

  • 1 × M.2 3052 B-key (4G/5G, USB 3.0 signal, external SIM slot)

• I/O Ports:

  • 4 × USB 3.1

  • 2 × USB 2.0

  • 4-pin GPIO

  • 2 × COM (RS232/RS485 optional)

  • 1 × Audio (Line-out / Mic combo)

• Mounting: VESA, wall mount, optional DIN-rail

• Operating Temperature: -20°C to +50°C (surface airflow)

• Humidity: 5% – 95% non-condensing

• Power Supply: DC 12V (5.5 × 2.5 mm connector)

• Dimensions: 186 × 140 × 66 mm

• Weight: 1.53 kg

• Security & Management: TPM 2.0, Wake-on-LAN, PXE boot, watchdog timer

• Applications: Industrial automation, medical devices, logistics, transportation, warehousing, e-learning, IoT edge computing
