PCB800807 Universal eDP TFT Display Control Board with Audio Input

Universal HDMI to eDP board with a maximum resolution of 1920x1200. Easy resolution configuration using jumpers, powered by 12V.

Specifications

  • Model: PCB800807
  • Chip: RTD2310E
  • Resolution: 1280x800, 1366x768, 1600x900, 1920x1080, or 1920x1200
  • Input: HDMI
  • Output: eDP, 30-pin FFC connector
  • Audio Input: No
  • Keyboard: Yes
  • Power: 12V
  • PCB Dimensions: 74x53mm

Package Includes:

1x Control Board
