WH5 - 5W, 395nm Desktop UV Lamp for Quick Curing

WH5 - 5W, 395nm Desktop UV Lamp for Quick Curing

High-power UV lamp designed for curing adhesives and coatings based on UV-sensitive materials. Compared to traditional UV tubes, it offers much faster and more efficient curing. For materials that typically require a ten-minute exposure, the curing time can be reduced to approximately 2 minutes.

The lamp is ideal for curing UV LOCA adhesives for re-bonding LCD displays and similar UV-sensitive materials, such as UV coating for non-solder mask.

EU adapter included!

Specifications:

• Model: WH5
• Light Type: LED
• Power Consumption: 5W
• Wavelength: 395nm
• Light Source: 5x 1W LG 45mil UV LED
• Cooling: Passive
• Irradiation Distance: up to 1 cm for maximum effect
• Dimensions (Width - Height - Depth) [mm]: 310x210x70mm
• Weight: 0.36kg
• Power Supply Voltage: 230V/50Hz
• Cable Length: ~1.2 m (EU)
• Packaging Weight [kg]: 0.6 kg
