Flexible Solar Panel 1.5V/250mA - FIT0333

A lightweight, thin, and versatile solar panel with a power output of 1.5V/250mA. Unlike traditional solar panels, it is truly flexible and can be bent, sewn, or adjusted within garments to conform to any surface. An excellent choice for DIY enthusiasts seeking an alternative energy source. Clean energy in a compact size and versatile format.

The black edges can easily be trimmed or sewn, and the panel is waterproof.

Note: The above electrical performance parameters were measured under standard testing conditions: light intensity of 1000W/㎡, spectrum AM1.5, cell temperature of 25℃.

SPECIFICATIONS

• Model: FIT0333
• Operating Voltage: 1.5V
• Open Circuit Voltage: 2V
• Operating Current: 200mA
• Short Circuit Current: 420mA
• Maximum Power: 0.5W
• Material: Monocrystalline silicon flexible laminate
• Connection Length: 1m
• Product Dimensions: 195mm*58mm*0.5cm
• Weight: 18 g ± 2 g
• Operating Temperature: -40℃~80℃
• Packaging Material: Durable, highly permeable ETFE material
• Adhesive: Fast-curing EVA-based adhesive that is weather resistant and has high permeability
• Cell Type: Flexible amorphous silicon thin-film solar cells with triple junction

APPLICATIONS

• Travel
• Offices
• Outdoor Camping

Installation: Wires should be carefully soldered to the two small metal rings on the back of the panel. The positive pole is marked with a sticker showing the symbol (+).
