DS18B20 Temperature Sensor HI-DS43-10 - Waterproof
Variants6
| Length | Availability | Price incl. VAT | Quantity (ks) | |||
|---|---|---|---|---|---|---|
 |
25cm | in stock | 3,80 EUR | |||
|
1m | in stock | 8,20 EUR | |||
|
2m | in stock | 5,30 EUR | |||
|
3m | in stock | 6,50 EUR | |||
|
5m | in stock | 8,20 EUR | |||
|
10m | Out of Stock Watch availability | 10,30 EUR | Demand |
DS18B20 temperature sensor, waterproof, 1 wire, Arduino
Technical product description
- Digital temperature sensor DS18B20 (non-original)
- Model: HI-DS43-10
- Measures temperature from -55 ℃ to +125 ℃
- Stainless steel probe suitable for wet or harsh environments
- Power supply range: 3.0V to 5.0V
- Accuracy in the range -10 ℃ to 85 ℃: ± 0.5 ℃
- VCC: /+/ red
- DATA: blue
- GND: /-/ black
- 1 x DS18B20 Waterproof Sensor
All DS18B20 sensors are based on the DS18B20 TO92 chip (non-original). The sensor tip has a length of 30 mm, width of 5 mm, AWG24 black PVC cable. For orders above 200 units, it is possible to customize the tip, cable, and connector based on your requirements. Larger orders and custom orders are processed within 10 business days.
Usage:
This sensor works in "parasitic" mode. This means it takes power from the data line and requires only two wires. The two wires can be directly connected to a TTL-to-USB adapter:
It is possible to connect multiple sensors in parallel:
In Windows, the temperature can be read using the "1-Wire" software from Maxim: 1-Wire Drivers x86
Third-party Windows software can also be used: LogTemp
In Linux, support is provided by the Digitemp low-level sensor driver: Digitemp sensor driver
